Name: Android 11.0 T982 Motherboard Interactive Whiteboard 75inch Display Support SKD/OEM Order with google Play
Brand: Hangzhou Gaoke Industry&trade Co., Ltd.
SKU: GK-880T/75S/H series
Availability: InStock

Home Products Model Q

Android 11.0 T982 Motherboard Interactive Whiteboard 75inch Display Support SKD/OEM Order with google Play

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	GAOKEview
Model Number:	GK-880T/75S/H series

Contact Now

Detailed Product Description

Folded:	NO	Whiteboard Type:	Interactive Flat Panel
Weight:	N.W.: 62 KGS / G.W.: 77 KGS	Color:	Black
Aspect Ratio:	1200:1	Package Dimensions:	1660mm1045mm245mm
Writing Method:	Pen/finger Touch	Product Dimension:	1456.3mm891.3mm96.1mm
Screen Size:	75 Inch	Whiteboard Type:	Interactive Whiteboard
Panel Size:	75inch, 75inches	Resolution:	3840x2160, 3840*2160
Touch Screen:	Infrared Touch	Aspect Ratio:	16:9
Screen Brand:	LG/BOE	Response Time:	6ms
Viewing Angle:	178°(H) / 178°(V)	Brightness:	400cd/m²(typ.)
Refreshing Frequency:	60HZ	Panel Type:	LED

GAOKEview Interactive Flat Panel Specification--Model D3-T982

Products Description

Product Paramenters

Model	GK-880T/65S-D3	GK-880T/75S-D3	GK-880T/86S-D3
Backlight Type	D-LED
Resolution(pixels)	3840x2160(pixels,RGB)	3840x2160(pixels,RGB)	3840x2160(pixels,RGB)
Brightness	350cd/m2(typ.)	350cd/m2(typ.)	350cd/m2(typ.)
Contrast Ratio	1200:1(typ.)	1200:1(typ.)	1200:1(typ.)
Response Time	8ms (typ.)	8ms (typ.)	8ms (typ.)
Pixel Pitch (mm)	0.4935(H)x0.4935(V)	0.4298(H)x0.4298(V)	0.4935(H)x0.4935(V)
Refreshing Frequency	60Hz	60Hz	60Hz
Viewing Angle	178°(H) / 178°(V)
Life Time	50,000 Hours (min.)
Color Gamut (X% NTSC)	72%(typ.)
View Area (mm)	1428.48(H)x803.52(V)mm	1649.74(H)x927.94(V)mm	1895.04(H)x1065.96(V) mm
Display Colors	1.07B(10bit)	1.07B(10bit)	1.07B(10bit)
System
Chipset			Amlogic T982
CPU	Architecture	Quad-core A55
		Working Frequency	1.9GHz
		Core	Quad Core
GPU			Mali G52MP2
RAM			4GB DDR4/6GB DDR4(Optional)/8GB DDR4(Optional)
ROM			EMMC 32GB/ 64GB(Optional) / 128GB (Optional)
OS			Android 11.0
Power Requirements			AC 100 V ~ 240 V, 50/60 Hz
Power Consumption Without OPS			65’’: 250W 75’’: 350W 86’’: 450W
Standby Condition			<0.5W
Audio Output Power			15W*2
I/O Interface
Rear Interface	RJ451; SPDIF OUT1; EARPHONE (3.5mm AUDIO OUT)1; AV IN1; AV OUT1; YPBPR IN1; VGA IN1; VGA AUDIO IN1; HDMI IN4; RS2321; TOUCH USB1; USB2.02
Front Interface	Public USB 3.03; Touch-USB1; HDMI IN1; Type-C1
Structure Parameter
Product Size(W x D x H)	1490.6904.888.95mm	1712.91030.989.15mm	1958.91169.7589.15mm
Package Size(W x D x H)	1576980200mm	17851125200mm	20401260200mm
Housing Material (Face frame/rear shell)	Aluminum/Metal Plate	Aluminum/Metal Plate	Aluminum/Metal Plate
Shell color (Face frame/rear shell)	Dark Gunmetal/Black	Dark Gunmetal/Black	Dark Gunmetal/Black
VESA	4-M8 Screw Hole 400mmx400mm	4-M8 Screw Hole 600mmx400mm	4-M8 Screw Hole 600mmx400mm
Net Weight	42±1KG	54±1KG	69±1KG
Gross Weight	56.5±1KG	69±1KG	83.8±1KG
OPS PC	Proecessor INTEL®CORE I3 ; RAM with 4 GB ; Storage SSD 128 GB ( OPTIONAL OR CUSTOMIZED )
